METRIC, Hex-Bolt plus Nut and Washers
M20 x Over 140mm Hex Bolt Nut Washers A2 304 Stainless Steel
M20 x Over 140mm Hex Bolt Nut Washers A2 304 Stainless Steel
Couldn't load pickup availability
Postal Notification: Royal Mail 48 delivers between 2-3 days, 97% of the time. Choose 1st or tracked at checkout for time sensitive shipments.
M20 x Over and Including 140mm, Hexagon Head, Partially Threaded Bolts in A2-70/ 304 Stainless Steel, DIN 931 plus Nut and Washers
Fixaball sells all lengths of M20 Hexagon Head Bolts in A2-70/ 304 Stainless Steel, plus Nut and Washers.
Hex-Bolt vs Hex-Set Screw
A set screw fastens materials together by twisting it directly through the last component, into a pre-threaded hole, pulling everything together. A shoulder bolt fastens materials by passing them through pre drilled holes in the adjoining materials and cramping them between the head at one end and a nut on the other. Additional washers are often used to spread the load further. A set screw is fully threaded from underneath the head and a bolt is partially threaded (has a part-plain shank). A bolt is used when you know the length you need and a set screw can be used as a bolt if you need more flexibility in the length.
Orders placed before 2pm are dispatched same day (Mon-Fri).
Standard, Free Delivery is Royal Mail, 2nd Class (2-5 days, most likely 2 days). For a faster delivery time, select 1st class or courier at checkout.
Please choose your, 'No. of Items in Pack', 'Length', and 'Quantity', of packs selection from the drop down menus.
M20 Hex Bolt Lengths available:
M20 X 140 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 150 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 160 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 170 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 180 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 190 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 200 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 210 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 220 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 230 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 240 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 250 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 260 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 270 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
M20 X 300 HEXAGON HEAD BOLT DIN 931 A2-70 STAINLESS STEEL |
Red = request lengths
Head Type
Hexagon Head.
Spanner Sizes
FIXABALL – Specialist Fixings and Fasteners Spanner Sizes METRIC - Hexagon Head Bolts/ Sets |
|
Thread Size/ Diameter |
Spanner Size |
M3 (3mm) |
5.5mm |
M4 (4mm) |
7mm |
M5 (5mm) |
8mm |
M6 (6mm) |
10mm |
M8 (8mm) |
13mm |
M10 (10mm) |
17mm |
M12 (12mm) |
19mm |
M14 (14mm) |
22mm |
M16 (16mm) |
24mm |
Threads
This listing is for standard coarse thread, shoulder bolts.
Metric Threads are measured in Millimetres (mm) units and were developed to simplify the imperial systems. Europe moved to this system but the Americans choose Imperial as their default. A coarse thread has less helical coils per mm and a fine one has more. Coarse is used for heavier loads and fine is used for lighter loads prone to vibrations.
Metric Threads/ Pitches |
|||
Fixaball – Specialists in Fixings and Fasteners |
|||
Pitch / Thread Types |
|||
Size |
Standard/ Coarse |
Fine |
Super Fine |
M1.6 |
0.35 |
||
M2 |
0.4 |
||
M2.5 |
0.45 |
||
M3 |
0.5 |
||
M4 |
0.7 |
||
M5 |
0.8 |
||
M6 |
1.0 |
||
M7 |
1.0 |
||
M8 |
1.25 |
1.0 |
|
M10 |
1.5 |
1.25 |
1.0 |
M12 |
1.75 |
1.5 |
1.25 |
M14 |
2.0 |
1.5 |
|
M16 |
2.0 |
1.5 |
|
M18 |
2.5 |
2.0 |
1.5 |
M20 |
2.5 |
2.0 |
1.5 |
M22 |
2.5 |
2.0 |
1.5 |
M24 |
3.0 |
2.0 |
|
M27 |
3.0 |
2.0 |
|
M30 |
3.5 |
2.0 |
|
M33 |
3.5 |
||
M36 |
4.0 |
||
M39 |
4.0 |
||
M45 |
4.5 |
||
M52 |
5.0 |
||
M56 |
5.5 |
Image is for illustrative purposes only.
